U-Cargo ‘Family’ Electric Bike by Add-Bike ™

The U-Cargo Family has been designed for the daily transport of 2 children, in complete safety and offering them the best comfort.

360° PROTECTION
The U-Cargo Family is equipped with a steel cabin to guarantee maximum safety for children.
The textile frame that covers it protects children from their shoulders to their feet.
Nothing better to not be cold in winter! Small +: this space will allow you to store groceries at their feet!
The step allows them to get on and off independently.
And the door, which only opens from the outside and sidewalk, allows them to learn the right gestures from childhood.

A POWERFUL AND RELIABLE ENGINE
Rolling with 100 kg of loads without getting exhausted: it’s possible!
With an engine torque of 80 Nm, it is easy to start empty or loaded without effort!
It is also equipped with an Easy-Start trigger allowing the engine to be started without giving the first pedal strokes: practical when you are loaded and/or uphill!
Thanks to a display and an application, you have the possibility of linking your telephone with the central engine of the U-Cargo and obtaining information on your journey and your use (kilometers travelled, battery status).

TRANSFORM THE CHILDREN’S AREA INTO STORAGE SPACE
The Switch2Carry function makes it easy and quick to transform the seat of the bike into a large 110L storage space: practical for going shopping after dropping the children off at school or nursery!

A BIKE MADE FOR THE CITY AND BEGINNERS
The frame is very easy to step over and designed for all sizes. Saddle and handlebars are adjustable.
It is also equipped with an Easy-Start trigger allowing the engine to be started without giving the first pedal strokes: practical when you are loaded and/or uphill! The front basket can also carry 20kg of additional loads (schoolbags, bags, etc.)

TECHNICAL SHEET
Frame: 6061-T6 painted aluminum frame (white)
Fork: 100mm fork wheelbase
User size: Optimized for sizes from 1.50m to 2m
Low leg opening
Adjustable saddle and stem
Handlebar: Rise: 75mm / Upsweep: 5° / Backsweep: 24° / Width: 68cm
Brakes: Hydraulic disc brakes: SHIMANO MT200
Wheels: Size 20”
Mach1: KARGO 20’’ – ETRTO 406x25C
Tires: Tire thickness 2.4
Schwalbe tires: 20×2.4″ ref Super moto-X Performance GreenGuard, SnakeSkin, 62-406 B/B-SK+RT HS439 ADDIX 67 EPI 33B
Seatpost: Adjustable suitable for all users
Bike weight: U-Cargo Family (with motor and battery): 45kg
Extra battery: 3.5kg
Drivetrain: Shimano Nexus hub – Gear Sensor
Shimano shifter: Shimano Acera SL-M315 7
Compatibility: Thule – Polisport – Decathlon – Hamax – Bobike
Volume available with metal frames at the back: 60cm x 50cm (length and width). Available volume: 90L (may be exceeded in height).
Engine: Bafang – BBS01
Position: Bottom bracket
Power: 250W
Torque: 80Nm
Smartphone app via Bluetooth: Bafang Go
Battery: Phylion – SF-06s
BAK cells
14.5Ah – 36V – 522Wh
700 charging cycles
Autonomy: 90km
Space available for 2nd battery
Payload: Rear load: 80kg
Front load: 20kg
Weight and Size: 40 kg – 205 cm (L) x 68 cm (W) x 110 cm (H)
Protech’360: 60 cm (W) x 110 cm (H)
Lights: Lite: Spanning: Front: Axendo 40Lux / Rear: Elips – 13 Cd
Handlebar: Rise: 75mm / Upsweep: 5° / Backsweep: 24° / Width: 68cm

DELIVERY :
The bike comes fully assembled.

GUARANTEE :
Designed and assembled in France
5 year warranty
The frame is guaranteed for 5 years, the electrical equipment for 2 years. Valid on defects in workmanship and/or materials.
